Get biomass- and numbers- by age plots with dual y-axis

Returns a dual-axis plot with numbers as bars and biomass as lines; each abundance measure is plotted on independent y-axis scales. Plot units are automatically scaled to millions of fish OR thousands of fish/ 1000s of tons OR tons based on the magnitude of the biomass (if there is greater than 1 million KG at any length, the larger scale is used).

Usage

plot_biomass_nums_by_age(
  age_vector,
  biomass_vector,
  numbers_vector,
  add_totals = FALSE,
  cex_label_size = 1
)

Arguments

age_vector

A vector of fish ages (units are assumed to be cm in 1 year increments). This vector must be equal in length to biomass_vector and numbers_vector.

biomass_vector

A vector of fish weights (units should be KG. Be sure to provide weights in KG!). This must should be equal in length to age_vector and numbers_vector.

numbers_vector

A vector of fish numbers (units should be individual fish. Be sure to provide weights in individual fish!). This must should be equal in length to age_vector and biomass_vector.

add_totals

Option to add the totals as the title of the plot. Default is to not add a title. Set to TRUE if you'd like a title with the total biomass and number values.

cex_label_size

the font size of the axis labels (default 1.0). These are specified as scaling factors from the default of 1.0 (i.e. 2 is twice as large).

Value

A ggplot plot object. Note that the actual plot is a R baseplot; it is returned as a ggplot object so that it can be more easily integrated into Rmarkdown documents.

Examples

# generate a simulated fish population
ages <- round(rnorm(mean = 5, sd =2, n = 100000), digits = 0)
numbers <- sample(c(0, 3e5), size = 100000, replace = TRUE)
weights <- (ages^3 * .02) * numbers

# plot it
plot_biomass_nums_by_age(age_vector = ages,
 biomass_vector = weights,
   numbers_vector = numbers)


# plot it with totals added as text
plot_biomass_nums_by_age(age_vector = ages,
biomass_vector = weights,
numbers_vector = numbers,
add_totals = TRUE)
